Machine learning helps Benteler with predictive quality control in production

by Autocar Pro News Desk , 21 Jun 2021


When machines learn which production data affect the quality of the product, quality deviations can be completely avoided. This makes production processes even better, faster and more reliable. German supplier Benteler is part of the ML4Pro2 research project (Machine Learning for Production and its Products) led by the Fraunhofer Institute for Mechatronic Systems Design.

The aim of the project is to make machine learning permanently available for intelligent products and production processes. For this purpose, Benteler says it is analysing data generated during the production of components in hot forming presses.

Detecting quality deviations based on temperature changes
Benteler uses hot forming technology primarily for customers in the automotive industry. The forming presses process sheet metal blanks into high-strength components, for example A and B pillars, frame parts, and cross and longitudinal beams. The quality of the various components is determined, among other things, by how the heat is distributed during the pressing process. Until now, quality control has been carried out at the end of the production process using an optical measuring station.

Now, as part of the research project, the automotive supplier is using a thermal imaging system that records the heat distribution of a component as soon as it leaves the press. This thermographic data is used as part of predictive quality control. The aim is to know in advance, based on the analysis of process heat, whether the pressed parts will meet the required quality – even before they leave the production process.

"Predictive quality is a key objective at Benteler. Our plan in the research project is to record and analyse the machine parameters of our hot forming presses. For example, we check precisely how temperature and pressure interact. This enables us to develop predictive models. Based on these, we can forecast whether the quality of our products is okay," says Daniel Kochling, Industry 4.0 manager at Benteler. "In the future, we will be able to react more quickly and change production parameters if necessary. This ensures that the temperature profiles of the components remain within tolerance and that quality improvements are possible during the ongoing process."

What's the ML4Pro2 project?
The ML4Pro2 project (Machine Learning for Production and its Products) started at the end of 2018 and will run until November 2021. The research and development project is funded by the Ministry of Economic Affairs, Innovation, Digitalization and Energy (MWIDE) of the German federal state of North Rhine-Westphalia. Under the leadership of Fraunhofer IEM, a total of 10 cooperation partners are participating in the project.
