Machine safety has become an increasingly important priority over the past 20 years for end users. This has ethical as well as economical reasons.
19 Nov 2014 | 4215 Views | By Autocar Professional Bureau
Machine safety has become an increasingly important priority over the past 20 years for end users. This has ethical as well as economical reasons: every workplace accident causes machine downtimes and costs. Therefore, standard-compliant machine safety is a significant success factor for OEMs in every market.
The trend toward ...
This is an Autocar Pro Plus article. Subscribe to continue reading.
Machine safety has become an increasingly important priority over the past 20 years for end users. This has ethical as well as economical reasons: every workplace accident causes machine downtimes and costs. Therefore, standard-compliant machine safety is a significant success factor for OEMs in every market.
The trend toward increased machine safety has significant effects for OEMs. Starting in the EU, the number of standards and norms has increased exponentially since the 1990s. Also, regional and national safety standards now apply more frequently in addition to international standards. OEMs with an international focus must implement the regulations of every target market in order to be able to market their products there.
Simultaneously, the content needs of state-of-the-art safety technology also has increased significantly. A complex system analysis of automation for the evaluation of machine safety has become the norm in nearly all markets. Control systems and software are central components in overlapping technologies.
Bosch Rexroth, a worldwide leading manufacturer of drive and control technologies, established a network of safety specialists within its global organization. They capture the requirements of the respective market and develop regionally adapted solutions. Rexroth makes this expertise available to OEMs and end users and therefore improves their chance for success on global markets. “Specifically smaller and mid-sized manufacturers like to take advantage of our services for machine safety,” says Michael Jochem, who is responsible for coordinating machine safety activities at Bosch Rexroth on an international level. This ranges from ready-to-install modules to complete engineering of safety solutions which includes extensive documentation.
“For many years we have noted the increase of machine safety regulations globally,” says Michael Jochem. “We see very different approaches to this in significant markets, some of which grew historically, but often also have industrial-political motivations.” This rule applies: the more international standards that apply in a market, the more open it is with greater machinery engineering export opportunities. The EU, China, and even Turkey have significantly reduced their share of national regulations over the past years.
This overview will show the wide variety of standards regarding machine safety in significant markets:
European Union: Pioneer for system approach
With the Machinery Directive 2006/42/EC, the European Union not only harmonized a plethora of national standards, it also introduced a new system that is a global role model. Since the end of 2009, only machines that comply with the Machinery Directive may be marketed within the EU. OEMs are responsible for this. They must document the functional safety of every machine and must include the documentation in the delivery.
“The Machinery Directive harmonized the system across all industries and applications,” says Wouter Leusden, Safety Specialist at Bosch Rexroth in Benelux. “Whether machine tools, packaging lines, or movable bridges: design engineers must always perform a risk assessment, define the required performance level for functional safety, and offer reliable realization with the respective system solutions.” In the handbook “10 Steps to Performance Level,” Bosch Rexroth has divided this complex process into practical work packages. “Engineers often have difficulties understanding the current standards,” explains Wouter Leusden. “Our handbook was written by experts for experts, and customers frequently confirm that the handbook has helped them.” The brochure “10 Steps to Performance Level,” which can be downloaded free of charge at www.boschrexroth.com/safety, offers a first overview of the handbook.
“Approximately 50 percent of safety-relevant standards and norms are globally valid IEC or ISO standards,” estimates Frederic Harmand, coordinating the Safety Specialists in France. “The other half comes from European institutions, for example the European Committee for Standardization (CEN) and the European Committee for Electro-Technical Standardization.“ In the process, the status of the European environment for standards has stabilized over the past five years. “This offers reliable framework conditions for OEMs,” says Frederic Harmand.
USA: On the way to harmonisation
The environment for standards in the US has grown historically and is very diverse. The number of standards and norms has increased significantly since the turn of the millennium. The absolute number of standards is even higher than in Europe. “This is primarily because the US has a plethora of state agencies on a national level and for each individual state, in addition to independent organizations, which issue standards,” explains Angela Patterson, Safety Specialist at Bosch Rexroth in the US. Her colleague Gary Thrall adds: “We clearly see a trend toward harmonizing American standards with European standards.”
Today, 70 percent of relevant regulations in the US already correspond to international or European standards. “Our customers in the US can profit from our extensive experience with European requirements,” explains Gary Thrall. But there are still standards specific to America. “We also support European OEMs in complying with these American regulations in order to be on the safe side,” says Angela Patterson.
China and Turkey: All focused on international standards
International standards simplify market access for all OEMs globally, while a high proportion of international standards favours the export opportunities of domestic OEMs. The basic concept of every machine or facility already takes these standards into consideration. This significantly reduces the adaptation requirement for other markets. Specifically, export-oriented nations like China or Turkey take this route.
“The topic of machine safety becomes more and more important for Chinese OEMs and they have quickly adjusted to international standards,” says Guihua Ying, Safety Specialist at Bosch Rexroth in China. “While many manufacturers initially focused on Asian and African markets, they now focus on the European and American markets that are highly regulated by standards.” This is where Chinese safety specialists can support compliance with additional, regional regulations.
“Atilla Yavuz describes the initial situation: “When it comes to machine safety, Turkey focuses almost exclusively on European and international standards.” In this, Engineering Department Manager at Bosch Rexroth in Turkey sees significant advantages for machinery construction. “Machinery construction is, after all, the second largest industry sector among Turkish exports,” says Atilla Yavuz. “The international harmonization of the standards environment reduces adaptation requirements for exports into other counties. With success: after all, Turkey's five largest OEMs export into more than one hundred countries.”
Other major markets like India are only starting this journey and are currently developing guidelines for machine safety.
Brazil: Regulations capture even installed machines
Brazil, as one of the BRICS states, has made great progress in terms of industrialization and is one of the most significant markets for machinery construction. “The number of standards for machine safety has doubled in the past five years, but Brazil focuses chiefly on international and European standards,” says Fernando Lopes. The Safety Specialist at Bosch Rexroth in Brazil points out that the standard NR12, which was revised in 2010, is closely related to the European Machinery Directive. Yet there is one important difference, emphasises his colleague Makoto Yokoyama: “NR12 also applies to machines and facilities that are already installed. Old facilities can be re-sold only if they comply with NR12.” Bosch Rexroth therefore retrofitted already more than 400 installed presses based on the new safety requirements.
“We work closely with European and American OEMs to develop standard-compliant machine concepts for the Brazilian market,” says Fernando Lopes of his daily work. “At the same time, we are the established contact person for end users when it comes to retrofitting their installed facilities, because Rexroth develops and implements standard-compliant, cross-technology solutions.”
